used for different kind of rubber product,clamping force more than 500 Tons.
a. Strong structure design, the main parts quality guarantee could be more than 5 years
b. Uniform temperature control, the temperature difference could be in ±1 ℃
c. Stable pressure control
d. Multi-stage pressure and temperature control
3.Specification:
|
Model |
Clamping Force (Tons) |
Platen Size (mm*mm) |
Daylight (mm) |
Diameter of Piston (mm) |
|
XLB-1000X1000 |
500 |
1000X1000 |
600 |
Φ600 |
|
XLB-1300X1300 |
700 |
1300X1300 |
700 |
Φ650 |
|
XLB-1600X1600 |
1000 |
1600X1600 |
900 |
Φ813 |
|
XLB-2000X2000 |
1600 |
2000X2000 |
1000 |
Φ1016 |
|
XLB-2200X2200 |
2000 |
2200X2200 |
1000 |
Φ1100 |
|
XLB-3000X3000 |
3000 |
3000X3000 |
1000 |
Φ1300 |
4.Options:
a.Temperature control boiler
b. Molds
